Embedded Module TQMa62LxxOA-S Embedded Cortex-A53 module based on TI AM62Lxx - the cost-efficient, performance-optimized family for applications such as HMI, control units, or home automation.
Embedded Module TQMa62LxxOA-S Embedded Cortex-A53 module based on TI AM62Lxx - the cost-efficient, performance-optimized family for applications such as HMI, control units, or home automation.
- Featuring new OSM –S Standard with 30x30mm
- Single / Dual Cortex A53 up to 1,25GHz
- 1x Display DSI / RGB
- High-speed communication via 2x Gbit Ethernet switch, 3 x CAN FD, 2x USB 2.0
- Integrated security functions
- Low power consumption (1-2 W)
The TQMa62LxxOA-S embedded module is based on Texas Instruments’ AM62Lxx processor family (Dual/Single Cortex-A53). The new solder-on TQMa62LxxOA-S is implemented in the compact OSM-S form factor (30 × 30 mm). The TQMa62LxxOA-S is ideally suited for applications such as basic HMIs, control and operator units, or home automation solutions.
This well-equipped CPU family is designed for low- to mid-range applications. With its broad range of interfaces – including 2× Gbit Ethernet switch, 3× CAN-FD, 2× USB 2.0, and a DSI display interface – the module covers a wide variety of use cases. Its very low power consumption of typically 1–2 W also enables use in handheld or battery-powered devices. Integrated security features such as Secure Boot complete the feature set of this well-rounded TI processor family.
CPU/Processor data
Max. CPU frequency:
- 1,25 GHz
CPU variant:
- AM62L32, AM62L31
CPU/Processor:
- AM62Lx
Memory
LPDDR4:
- Up to 2 GB
eMMC:
- Up to 128 GB (256 GB 3D NAND)
Graphics
Display:
- 1x DSI / RGB (24 bit)
Communication interfaces
Ethernet:
- Up to 2x Gbit-Ethernet switch (TSN)
USB:
- Up to 2x USB 2.0 interface
CAN:
- Up to 3x CAN FD
Serial Ports:
- Up to 8x UART
Other interfaces
I2C:
- Up to 5x I2C
SD Card:
- Up to 2x SDIO
SPI:
- Up to 4x SPI
- Up to 1x OSPI
GPMC:
- Up to 1x GPMC
PWM:
- Up to 3x PWM
Audio:
- 3x McASP
Debug:
- JTAG
Other functions
RTC:
- Real Time Clock (RTC)
General:
- Temperature sensor
General data/basic data
Dimensions:
- OSM - S: 30 mm x 30 mm
Temperature range:
- Standard temperature range: -25°C…+85°C
- Extended temperature: -40°C…+85°C
Plug-in System:
- Board-to-board plug-in system 332 pins, 1,25 mm pitch, OSM–S-Standard
Power supply:
- 5 V
Power consumption:
- Power dissipation: 1-2 Watt
OS-Support
OS Support:
- Linux
- Armbian on Request
Prototypes
Prototypes coming soon (Q2/26)
