New TQ platform based on Layerscape Dual Cortex-A72 technology TSN switch and integrated graphics capabilities

The technology company TQ is expanding its product portfolio with a new platform based on the 64-bit Cortex®-A72 QorIQ® Layerscape® processor family LS1028A from NXP. The MBLS1028A-IND is particularly suitable for robust and industrial applications in the field of high-speed data communication and offers TSN support in combination with powerful graphics.

MBLS1028A

Mainboard MBLS1028A including embedded module TQMLS1028ADownload image

The core of the platform, which is available both as a mainboard and as a complete device, is the TQMLS1028A module. For the TQMLS1028A, TQ relies on the NXP processor family Arm® Layerscape LS1028A. Based on this CPU, four different pin-compatible CPU variants are available depending on the required functionality. Alternatively to the two single-core variants (LS1017A and LS1018A), the dual-core variants (LS1027A and LS1028A) are available. The CPUs LS1017A and LS1027A have deactivated graphic functions. The integrated graphics of the LS1018A and LS1028A support displays up to 4K resolution with a powerful GPU. Combined with a clock rate of up to 1.3 GHz, the TQMLS1028A provides a comprehensive and scalable platform with low power dissipation.

Four Gigabit Ethernet interfaces are available on the mainboard with compact dimensions of 160 x 100 mm for fast data communication, which are implemented via a TSN-capable Ethernet switch. Additionally, users can rely on two independent interfaces for Gigabit Ethernet.

In addition to the Ethernet interfaces, the user has an M.2 SATA for connecting an SSD and a Mini PCIe slot with SIM card for expansion for wireless solutions such as LoRaWan, Sigfox, WiFi and mobile communication. In addition, two USB 3.0 interfaces and two galvanically isolated CAN interfaces are available. The embedded DisplayPort allows the connection of a monitor for a screen resolution of up to 4K.

Lbox-LS1028A

Box-PC LBox-LS1028A Download Image

The design of the MBLS1028A-IND includes sufficient high-speed interfaces for the use in applications such as a TSN switch, edge server, Ethernet gateway or an industrial router. In combination with an enclosure, the MBLS1028A-IND works as a Box PC.

The platform guarantees a fast, secure and real-time capable data communication in combination with low power dissipation. The MBLS1028A-IND also works in robust and industrial applications in the field of high-speed data communication, automation and control systems.

The MBLS1028A is now available.

9920

Unless otherwise stated, TQ-Systems GmbH is the copyright holder of the images used in this press release. These pictures can be used free of charge if the author is named.
