Simple, space-saving installation
Seamless integration into your system,
Connects 6 transducers to just 2TE
SU100
Indirect measurement with up to 6 transducers for all applications.
NEW NOW!
The new SU100 variant with up to 6 connection points, while maintaining the compact 2 TE installation space and simple, flexible connection configuration.
All SU100 variants are CRA-ready and have been developed in accordance with DIN EN IEC 62443-4-2 – for the highest security standards and future-proof applications.
The advantages of the SU100
Areas of application of the SU100
- Indirect measurement for residential and commercial applications
- Submetering for energy flow analysis
- Data acquisition for HEMS systems
- Energy optimization
- OEM integration in energy management solutions
Features and Highlights
Indirect measurement from 63 A to 600 A
For power consumption and supply at up to 6 measurement points
Precise 4-quadrant meter
Measurement of active power, reactive power and energy flows
Versatile connectivity
Modbus RTU/TCP/TLS, Sunspec, MQTT (roadmap), RS-485, LAN
Simple web configuration
via HTTPS, with role rights and encrypted communication
OTA updates & mDNS support
Central administration and simple integration
Cybersecurity
CRA-ready, developed in accordance with DIN EN IEC 62443-4-2
OEM-capable & customizable
Three product variants: R / LR / LR+, customer-specific adaptations
Compact & efficient
Only 2 HP wide, < 2 W power consumption
Individual OEM solutions possible
Tailored to your look & feel or quickly on the market with a TQ proprietary product.
Connectivity for every application
Modbus RTU, TCP, Sunspec or proprietary protocols can be customized to your individual OEM product if required.
High resolution up to 20 ms
All measured values are available with 100 ms, selected measured values can optionally be retrieved with a resolution of up to 20 ms.
Seamless Integration
Tailor-made solution that integrates effortlessly into your system, e.g. thanks to mDNS, and simplifies commissioning – without having to enter IP addresses.
Security and Future Viability
SU100 meets the highest demands for cybersecurity and is already prepared today for the requirements of the Cyber Resilience Act (CRA). Thanks to OTA update capability, encrypted protocols, and role-based web access, SU100 offers maximum data security – even in sensitive applications.
Made in Germany - with the TQ factor
As part of the TQ Group, the SU100 is manufactured entirely in Germany - fully automated, scalable and to industrial quality standards. This means you benefit from a reliable supply chain, short distances, direct communication and an experienced development partner with over 1 million energy measurement systems delivered.
Downloads SU100
Data sheets
Firmware & Release Notes
Installation instructions
Declarations of conformity
