Embedded Module TQMa62xx Embedded Cortex®-A53 module based on TI AM62xx for applications with enhanced computing & scalable graphics performance
Embedded Module TQMa62xx Embedded Cortex®-A53 module based on TI AM62xx for applications with enhanced computing & scalable graphics performance
- 4/2/1 Cortex A53 - scalable computing performance
- Dual Display LVDS / RGB + 3D GPU
- LPDDR4 support with ECC
- High-speed communication via 2x Gbit Ethernet switch (TSN), 3 x CAN FD, 2x USB 2.0 interface
- Low power consumption (typ. 2W)
- Integrated security functions
The embedded module TQMa62xx, is based on the processor family AM62xx (Quad /Dual / Single Cortex A53) from Texas Instruments. This module is designed to use the pin-compatible processors on one module design. This module is ideal for applications that require advanced computing power and scalable graphics performance. The AM62xx family is introduced as the successor to TI's AM335x family.
This CPU family offers a performance plus in graphics, computing power and a variety of industrial interfaces. These include 2x Gigabit Ethernet switches with TSN support. In addition, they have various interfaces such as USB2.0, CAN-FD, UART and CSI. The overall package is rounded off by a Cortex A53 which, in addition to dual display (LVDS/ RGB), has an optional 3D GPU.
CPU/Processor data
CPU variant:
- AM6254
- AM6252
- AM6251
- AM6234
- AM6232
- AM6231
CPU/Processor:
- Cortex®-A53 - Up to 1,4GHZ
Memory
LPDDR4:
- Up to 2 GB
NOR Flash:
- Up to 256 MB
eMMC:
- Up to 64 GB
EEPROM:
- 0/64-kbit
Graphics
Graphic interface:
- 1x LVDS (4 lanes)
- 1x RGB (24bit)
- 3D GPU (8G FLOPFS)
Camera interface:
- 1x CSI-Rx (4 lanes)
Communication interfaces
Ethernet:
- Up to 2x Gbit-Ethernet (TSN)
USB:
- Up to 2x USB 2.0 interface
CAN:
- Up to 3x CAN FD
Serial Ports:
- Up to 9x UART
Other interfaces
SD Card:
- Up to 3x SDIO
I2C:
- Up to 6x I2C
SPI:
- Up to 5x SPI
- Up to 1x OSPI
GPMC:
- Up to 1x GPMC
PWM:
- Up to 3x PWM
Audio:
- 3x McASP
Other functions
RTC:
- Real Time Clock (RTC)
Secure Element:
- SE050
General:
- Temperature sensor
General data/basic data
Power supply:
- 3.3 V
Dimensions:
- 58 mm x 32 mm
Temperature range:
- Standard temperature range: -25°C…+85°C
- Extended temperature: -40°C…+85°C
Plug-in System:
- Board-to-board plug-in system 320 pins (TBD) 0.5 mm Pitch
OS-Support
OS Support:
- Linux
Download Subscription
With the free download subscription, registered users receive automatic e-mail notifications as soon as there are new downloads for this TQ product. How-to-guide
TQMa6231L-AA
TQMa6231L-AA, Quad Cortex®- A53 / 1,4GHz, Cortex®- M4 / 400MHz, 1GB LPDDR4, 8GB eMMC, 64 kB EEPROM, RTC, -40°C...+85°C
TQMa6254L-AA
TQMa6254L-AA, Quad Cortex®- A53 / 1,4GHz, Cortex®- M4 / 400MHz, 1GB LPDDR4, 8GB eMMC, 64 kB EEPROM, RTC, with 3D GPU support, -40°C...+85°C
